A nimble, dependable fat tire e-bike that's approachable without sacrificing capability. Designed for riders who are new to fat tire bikes or simply prefer a lighter, more agile ride without giving up any of the fun.
| Reach | 19" |
| Top Tube Length | 25" |
| Standover Height | 16" |
| Wheelbase | 46" |
| Min Saddle Height | 30" |
| Max Saddle Height | 35" |
| Total Length | 68" |
| Head Tube Length | 6" |
| Battery | 48V 19.6Ah , Complies with UL standards, IPX7 Waterproof |
| Charger | 48V 3A |
| WATERPROOF RATING | IPX6 (Whole Bike) |
| Motor | Continuous Power: 750W Peak Power: 1100W Torque: 90Nm+ |
| Speed Class |
20 mph (Throttle) / 28 mph (PAS) |
| Weight |
82 lbs |
| Range |
60~80miles |
| Payload Capacity |
350 lbs |
| Sensor | Torque+Cadence Sensor |
| Brakes | TEKTRO TKD171 Hydraulic Disc Brakes |
| Brake lever | Aluminum Alloy, with power cutoff |
| Tires | 20"x 4.0" Fat Tire (Puncture-Resistant) |
| Display | Detachable High-Definition Display |
| Derailleur | 8 Speed Shimano |
| Chain | KMC Stainless Chain |
| Crank Set | Aluminum alloy, 170mm, 52T chainring |
| Front Fork | 100mm fork travel |
| Frame | 6061 Aluminum Alloy |
| Gearing | Shimano 8-Speed |
| Throttle | Thumb Throttle |
| Handlebar | Aluminum Alloy, φ31.8mm, 680mm |
| Kickstand | Sturdy Aluminum Alloy |
| Rims | Aluminum Alloy |
| Saddle | Customized Comfort Leather Seat |
| Spokes | Heavy-duty carbon steel, 13G × 172 mm (front) / 123 mm (rear) , 13G × 172 mm (front) / 125 mm (rear) |
